ELECTRONICS AND COMMUNICATION ENGINEERING

LABS

Laboratory Facilities Available in the Department:-
  1. Electronic Devices and Circuit Lab
  2. Digital Electronics Lab.
  3. Semiconductor Device Lab
  4. Communication Engineering Lab
  5. VLSI Lab
  6. Digital Signal Processing Lab
  7. Electromagnetic Computation and Simulation Lab
  8. Project Lab
  9. Signal Processing Research Lab.
  10. Wireless Propagation Lab.
  11. Optical Fiber Communication & Photonics Research Lab
  12. Microprocessor & Microcontroller Lab
  13. VLSI Fabrication Lab
  14. WSN Lab
  15. Image Processing Lab
labsPiclabsPic
Important Software:
  1. CST(full package)
  2. HFSS(full package)
  3. IE3D
  4. MATLAB
  5. NI LAB View
  6. Multisim
  7. OptiSuite(full package)
  8. Cadence
  9. Synopsis
  10. Mentor graphics
  11. Vivado Xilinx
  12. RSoft FemSIM
  13. COMSOL with Wave Optics module
  14. Xilinx SDSOC
  15. Mentor Catapult (C/C++/SystemC HLS)
  16. Xilinx Vivado System Edition with Partial Reconfiguration
labsPiclabsPic
Major Equipment:
  1. Dell Blade Server
  2. HP Blade Server
  3. Agilent E8257D PSG Analog Signal Generator (250 kHz to 40 GHz)
  4. Agilent N5222A PNA Vector Network Analyzer (10 MHz to 26.5 GHz)
  5. Agilent N9020A MXA Signal Analyzer (10 Hz to 26.5 GHz)
  6. Rudimentary Antenna Radiation Pattern Measurement Setup (40 MHz to 12.4 GHz) from Amitec
  7. MITS ELEVEN-Lab PCB Prototyping Machine (Resolution: 0.625 micron)
  8. ERSA i-CON VARIO 4 High Precision 4 Channel Soldering/De-soldering Station
  9. NI USRP-Rio Software Defined Radio Platform (440 MHz to 4.4 GHz)
  10. Tektronix 1 GHz Mixed Signal Oscilloscope
  11. Two SMC 100A Signal Generators (9 kHz to 3 GHz) from Rohde & Schwarz
  12. Anritsu VNA MS2037C (5 kHz to 15 GHz) and Spectrum Analyzer (9 kHz to 15 GHz)
  13. 2231A-30-3 Triple Channel DC Power Supply from Keithley
  14. Software Controlled Motorized Antenna Positioner (azimuth and elevation) from Holmarc
  15. Zedboard (For Embedded Application)
  16. Xilinx Zynq UltraScale+ MPSoC ZCU102 Evaluation Kit
  17. Xilinx Zynq 7000 AP SoC ZC702 Evaluation Kit
  18. Zybo Board (For Internet of Things Lab)
  19. Multiple Instrumentation Lab
  20. NI 9792: WSN Gateway with NI WSN 3214, NI WSN 3226, and NI WSN 3212
  21. OTDR and Optical Network Building Block system
  22. Physics of Fiber Optics Lab Setup
  23. Soldering De-soldering Station
labsPiclabsPiclabsPic
